Turntable Feeder
Industries
EV & New Energy Vehicles
Automotive Electronics
Automotive Components
3C Electronics
Telecommunications
Home Appliances
Pharmaceutical
Features
High-Efficiency Screw Feeding
Feeds over 100 screws per minute in track arrangement, precisely matching high-speed production line cadence.
Wide Compatibility
Supports screws with length-to-diameter ratios from 1.2 to 4.0, including challenging special screws with spring washers.
Ultra-Low Jam Rate
Standard screws jam rate < 0.01%, spring washer screws jam rate < 0.03%, ensuring uninterrupted production.
Energy Efficient & Reliable
Centralized mechanical sorting design reduces air consumption by 40%, unaffected by air supply fluctuations.
Intelligent Interaction
High-definition HMI for real-time equipment monitoring and I/O signals, one-touch parameter setup, boosting maintenance efficiency by 50%.
Specifications
|
Basic Specifications |
Capacity |
Applicable Screw Range |
Applicable Head Diameter |
Applicable Screw L/D Ratio |
Cycle Time |
Machine Weight |
Main Pneumatic Brands |
|
1.5L |
M2-M6 |
3<D≤12mm |
1.2<L/D≤4 |
1.1-2.5 s/pcs |
25kg |
FESTO/SMC |
|
Equipment Specifications |
Power Supply |
Rated Air Pressure |
Air Consumption |
Air Inlet Pipe Diameter |
I/O Cable Length |
Power Cable Length |
Screw Feeding Tube Length |
|
220V/50Hz |
04-0.6Mpa |
2-3L/Sec |
φ8 |
5m |
3m |
5m |
Related Products
Cleaning Module
· Combines airflow and vacuum extraction to remove debris and oil without damaging plating.
· Integrated sensors and counting functions prevent assembly failures and electrical shorts.
Short/Long Fastener Detection Module
· Integrated through-beam fiber optic sensors for adaptive detection of diverse fastener specifications.
· Ensures 100% rejection of unqualified parts to eliminate seating errors and stripped threads.
· Optimized for automotive and 3C electronics to maximize production yield and changeover efficiency.
Tightening Module
· TCHSOON offers a versatile range of tightening modules engineered for seamless adaptation to diverse assembly requirements.
· Explore our "Tightening Modules" section for detailed specifications and application scenarios.
