Maglev Conveyor System
Industries
Automotive & EV Manufacturing
Heavy Machinery & Equipment
Heavy Machinery & Equipment
Metalworking & Metallurgy
Intelligent Warehousing
Aerospace & Rail Transport
Home Appliances (Heavy Goods)
Features
Ultra-High Precision Positioning
Achieves positioning accuracy up to ±5μm, ideal for high-precision industries like semiconductor, medical devices,and precision optics.
Extremely Flexible Control
Features independent mover control with millisecond start-stop and arbitrary stopping capabilities. Enables smart mixed-production and seamless line to significantly boost production efficiency. coordination
High-Speed Operation
Delivers ultra-high speeds up to 4m/s, offering production capacity more than three times greater than traditional conveyor lines.
User-Friendly Operation
Equipped with an intuitive graphical task editor, enabling users with no experience to quickly set up, configure, and debug production lines.
Flexible and Adaptable Design
The modular track design supports seamless splicing into various shapes—including circular, square, and complex layouts—allowing perfect adaptation to diverse production needs and spatial constraints.
Product Structure
Specifications
|
Track Layout |
Rectangular, square, circular, straight, L-shaped, U-shaped, O-shaped, Z-shaped, T-shaped, or any custom shape |
| Motor Module Length |
300mm |
| Rated Continuous Force |
Coreless: <50N / Iron Core: <400N |
| Peak Force |
>2 × Rated Continuous Force |
| Load Capacity |
Coreless: <20kg / Iron Core: <200kg |
| Overload Factor |
120%*In |
|
Mover Max. Speed |
4m/s |
|
Mover Acceleration |
>10g (excluding payload) |
|
Mover Repeat Positioning Accuracy |
Coreless: <±5 μ m / Iron Core:±10 μm |
|
Motor Supply Voltage |
48V±10% |
|
Single Module Rated Power |
450W @ 48V rated voltage |
|
Single Module RatedCurrent |
10A @ 48V rated voltage |
|
Mounting Orientation |
Vertical/Horizontal |
|
Ingress Protection (IP) |
IP54 |
|
Operating Temperature |
-40~65°C |
|
Storage Temperature |
-40~85°C |
|
Vibration/Shock Resistance |
4.9m/s² | 19.6m/s² |
|
Overload Capability |
200% for 1 minute |
